The Three Dimensions of System Design: The Art of Blending

Welcome to the final instalment in our series exploring the fundamental dimensions of system design! After examining Consistency, Communication, and Coordination models individually, it's time to understand how they work together to create different architectural patterns.

The “Quite A Lot Of Possible” Combinations

When we combine our three dimensions:

• Consistency: Atomic vs Eventual

• Communication: Sync vs Async

• Coordination: Orchestrated vs Choreographed

We get eight possible combinations:

1. Atomic + Sync + Orchestrated (ASO)

2. Atomic + Sync + Choreographed (ASC)

3. Atomic + Async + Orchestrated (AAO)

4. Atomic + Async + Choreographed (AAC)

5. Eventual + Sync + Orchestrated (ESO)

6. Eventual + Sync + Choreographed (ESC)

7. Eventual + Async + Orchestrated (EAO)

8. Eventual + Async + Choreographed (EAC)

Let's examine these combinations in two categories: Common Patterns and Specialised Patterns(not so common for a reason).

Common Patterns | Most used

These patterns are widely used and proven in production environments.

1. The "Strong Consistency" Pattern (ASO)

Atomic + Sync + Orchestrated

Perfect for:

• Financial transactions

• Booking systems

• Inventory management

• Critical business operations

NFR Alignment:

• Reliability: ⭐⭐⭐⭐⭐

• Availability: ⭐⭐

• Scalability: ⭐

• Performance: ⭐⭐

• Maintainability: ⭐⭐⭐⭐

Real-world example: Banking transaction system where every step must be verified and controlled.

When to use: When immediate consistency and process control are non-negotiable requirements.

2. The "Reliable Processing" Pattern (AAO)

Atomic + Async + Orchestrated

Perfect for:

• Payment processing

• Order fulfillment

• Multi-step workflows

• Compliance systems

NFR Alignment:

• Reliability: ⭐⭐⭐⭐⭐

• Availability: ⭐⭐⭐

• Scalability: ⭐⭐⭐

• Performance: ⭐⭐⭐

• Maintainability: ⭐⭐⭐⭐

Real-world example: E-commerce order processing where steps must complete but can be processed asynchronously.

When to use: When you need strong consistency guarantees but can afford to wait for completion.

3. The "Balanced Scale" Pattern (EAO)

Eventual + Async + Orchestrated

Perfect for:

• Data synchronisation

• Report generation

• Content processing

• Batch operations

NFR Alignment:

• Reliability: ⭐⭐⭐⭐

• Availability: ⭐⭐⭐⭐

• Scalability: ⭐⭐⭐⭐

• Performance: ⭐⭐⭐⭐

• Maintainability: ⭐⭐⭐

Real-world example: Content management system processing and distributing updates.

When to use: When you need process control but can work with eventual consistency.

4. The "High Scalability" Pattern (EAC)

Eventual + Async + Choreographed

Perfect for:

• Social media feeds

• Analytics systems

• Content delivery

• Event-driven systems

NFR Alignment:

• Reliability: ⭐⭐⭐

• Availability: ⭐⭐⭐⭐⭐

• Scalability: ⭐⭐⭐⭐⭐

• Performance: ⭐⭐⭐⭐⭐

• Maintainability: ⭐⭐⭐

Real-world example: Social media news feed where posts eventually appear across the network.

When to use: When maximum scalability and availability are primary concerns.

Specialised Patterns

These patterns are more situational and often require careful consideration before implementation.

5. The "Distributed Consensus" Pattern (ASC)

Atomic + Sync + Choreographed

Challenging because:

• Achieving atomic consistency in a choreographed system is complex

• Synchronous communication can create bottlenecks

• Hard to maintain atomic guarantees without central control

NFR Alignment:

• Reliability: ⭐⭐⭐

• Availability: ⭐⭐

• Scalability: ⭐⭐

• Performance: ⭐⭐

• Maintainability: ⭐⭐

Real-world example: Distributed voting system requiring immediate consensus.

When to use: Only when you need atomic guarantees in a distributed system and can accept the complexity and performance impact.

6. The "Distributed Atomic" Pattern (AAC)

Atomic + Async + Choreographed

Challenging because:

• Complex to implement atomic guarantees across distributed processes

• Requires sophisticated compensation mechanisms

• Hard to debug and maintain

NFR Alignment:

• Reliability: ⭐⭐⭐

• Availability: ⭐⭐⭐

• Scalability: ⭐⭐⭐

• Performance: ⭐⭐⭐

• Maintainability: ⭐⭐

Real-world example: Distributed reservation system with eventual booking confirmation but atomic guarantees.

When to use: When you need atomic guarantees in a distributed system but can accept eventual completion.

7. The "Controlled Convergence" Pattern (ESO)

Eventual + Sync + Orchestrated

Challenging because:

• Mixing eventual consistency with sync operations can be confusing

• May indicate design issues

• Can create unnecessary waiting

NFR Alignment:

• Reliability: ⭐⭐⭐

• Availability: ⭐⭐⭐

• Scalability: ⭐⭐

• Performance: ⭐⭐

• Maintainability: ⭐⭐⭐

Real-world example: Status dashboard system with immediate updates but eventual consistency across regions.

When to use: When immediate response is needed but eventual consistency is acceptable for the final state.

8. The "Immediate Response" Pattern (ESC)

Eventual + Sync + Choreographed

Challenging because:

• Sync communication can negate benefits of eventual consistency

• Can create unnecessary coupling

• May indicate architectural confusion

NFR Alignment:

• Reliability: ⭐⭐

• Availability: ⭐⭐⭐

• Scalability: ⭐⭐

• Performance: ⭐⭐

• Maintainability: ⭐⭐

Real-world example: Real-time collaboration system with immediate local updates but eventual global consistency.

When to use: Rarely recommended - consider async alternatives.

Architect's Alert 🚨

When selecting a pattern, consider:

1. Your Primary NFRs

   • Which qualities are most important?

   • What can you trade off?

   • What must you guarantee?

2. System Context

   • Scale requirements

   • Geographic distribution

   • Team capabilities

   • Operational maturity

3. Business Requirements

   • Consistency needs

   • Response time requirements

   • Regulatory requirements

   • Cost constraints

Best Practices

1. Start Simple

   • Choose common patterns first

   • Add complexity only when needed

   • Document your rationale

   • Monitor system behaviour

2. Mix Patterns Carefully

   • Define clear boundaries

   • Document interactions

   • Monitor integration points

   • Plan for evolution

3. Review Regularly

   • Assess pattern effectiveness

   • Monitor NFR alignment

   • Gather team feedback

   • Plan improvements

Conclusion

Understanding these eight combinations helps make better architectural decisions. While the common patterns will serve most needs, knowing when and why to use specialised patterns is crucial for handling unique requirements effectively.

Remember: The best pattern is the one that meets your specific needs while maintaining system simplicity and manageability.
